Engine

• Valve mechanism

  16-Valve DOHC, Chain Drive (With VVT-iE and VVT-i)

• Fuel Injection System

  SFI

• Displacement (cc)

  1798 ccm

• Maximum Output (kW@rpm)

  103 kW@rpm

• Maximum Torque (Nm@rpm)

  142/3600- Nm@rpm

• Total Hybrid System Output (DIN hp)

  140 DIN hp

• Electric Front Motor: Type

  Permanent magnet synchronous motor

• Maximum output (DIN hp)

  140 DIN hp

• Conventional engine output (DIN hp)

  98 DIN hp

• Electric Front Motor: Maximum Output (kW)

  70 kw

• Electric Front Motor: Maximum Torque (Nm)

  185 Nm

• Engine Code

  2ZR-FXE

• Hybrid Vehicle Battery: Type

  Lithium-ion-battery

• Hybrid Vehicle Battery: Capacity Ah (hr)

  4.08 Ah

• Battery Capacity (Ah)

  4.08 Ah

Transmission

• Transmission Type

  CVT

• Drive

  FWD

• Differential Gear Ratio

  3.016

Performance

• Maximum Speed (km/h)

  170 km/h

• Acceleration 0-100 km/h

  10.2 seconds

• Drag Coefficient

  0.318

Suspension

• Suspension Front

  MacPherson Strut

• Suspension Rear

  Double wishbone

Brakes

• Brakes Front

  Ventilated disc 1-cylinder

• Brakes Rear

  Solid disc 1-cylinder

Weights & towing capacity

• Gross Vehicle Weight - Total (kg)

  1930 kg

• Kerb Weight (kg)

  1430-1455 kg

• Towing Capacity With Brakes (kg)

  725 kg

• Towing Capacity Without Brakes (kg)

  725 kg

• Gross Vehicle Weight - Rear (kg)

  1080 kg

• Kerb weight min (kg)

  1430 kg

Exterior dimensions

• Length (mm)

  4362 mm

• Width (mm)

  1832 mm

• Height (mm)

  1558 mm

• Wheelbase (mm)

  2640 mm

• Front Tread (mm)

  1570 mm

• Rear Tread (mm)

  1585 mm

• Overhang Front (mm)

  911 mm

• Overhang Rear (mm)

  811 mm

Interior dimensions

• Number Of Seats

  5 seats

Luggage compartment

• Luggage Capacity (litres)

  388 liters

• Load Volume (m³)

  0.388 m³

• VDA luggage capacity, rear seat up (litres)

  388 liters

Steering

• Minimum Turning Radius (m)

  5.5 m

Off Road

• Minimum Running Ground Clearance (mm)

  161 mm

• Approach Angle (°)

  14 °

• Departure Angle (°)

  27 °

Wheels

• Silver large centre cap surrounds

• Tyre repair kit

Styling

• Body-coloured front bumper

• Body-coloured door handles

• Black centre pillar design

• Black wheel arch moulding

• Black painted insert on boot door

• Body-coloured rear spoiler

• Body-coloured roof

• Rear bumper with gunmetal insert

• Gunmetal surround on lower front grille

• Grained rear bumper extension

• Grained front side grille

• Grained lower front grille

Comfort

• Follow-me-home headlights

• Dusk sensor

• Automatic headlight cut-off

• Headlight cut-off reminder

• Lockable tailgate

• Boot door release with push button

• Standard opening of boot or tailgate

• Remote boot door release in cabin

• Power-adjustable door mirrors

• Heated door mirrors

• Remote door lock

• Smartphone remote door lock

• Smartphone remote hazard lights system

• Flush front door handles

• Flush rear door handles

• Standard roof

Transport

• Pre-wiring for towing hook

Safety

• Intelligent front parking sensors with automatic braking

• Rear-view camera

• Road Sign Assist (RSA)

• Automatic High Beam (AHB)

• Blind Spot Monitor (BSM)

• Daytime running lights (LED type)

• Front fog lamps (LED type)

• Adjustable Speed Limiter (ASL)

• Anti-lock Braking System (ABS) with Electronic Brake force Distribution (EBD)

• Emergency Brake-light Signal (EBS)

• Rear combination lamps (LED type)

• Hill-start Assist Control (HAC)

• Tyre Pressure Warning System (TPWS)

• Vehicle Stability Control (VSC)

• Intrusion alarm

• Immobiliser

• High-mounted stop lamp (LED type)

• LED rear brake lights

• Rear Cross Traffic Alert (RCTA)

• eCall emergency call system

• Memory on speed limiter

• Lane Trace Assist (LTA)

• Reflector LED headlamps

• Emergency Steering Assist on Pre-Collision system

• Intelligent Adaptive Cruise Control (iACC)

• Safe Exit Assist

• Front-to-front Oncoming Car and Motorbike detection (day) on Pre-Collision system

• Automatic Rear Flashing Hazard Lights (ARFHL)

• Pre-Collision System with Pedestrian & daytime Cyclist and Motorbike detection

• Intelligent Clearance Sonar (ICS) (rear, for objects and vehicle)

• Emergency Driving Stop System (EDSS)

• Rear parking sensors (4)

• Road Events

• Pre-Collision System with Intersection Collision Avoidance support

• Rear fog lamps (LED)

• Turning signal integrated in door mirrors (LED)

• Acceleration Suppression at low speed

• 16" brake disc

• Proactive Driving Assist (PDA)

Multimedia

• Aux-in connector

• Bluetooth® hands-free system

• Digital Audio Broadcast (DAB)

• 6 speakers

• 8" multimedia display

• MyT Connected Services

• USB connector integrated with radio and CD player

• Microphone on front personal lamp

• Wireless Smartphone Integration

• Smart voice assist

• Front USB Type-C connector

• Toyota Smart Connect

• Cloud Navigation

Styling

• Black centre air vent

• Satin chrome centre air vent surrounds

• Satin chrome insert on centre air vents

• Satin chrome side air vent surrounds

• Satin chrome insert on side air vents

• Electronic parking brake

• Fabric front door trim

• PVC gear shift knob

• Dark grey interior door handles

• 3-spoke synthetic leather steering wheel

• Fabric rear door armrests

Comfort

• Dual-zone automatic air conditioning

• Push-button start

• Analogue speedometer

• Analogue tachometer

• Electric Power Steering (EPS)

• Manual day/night rear-view mirror

• Rear-view camera display in audio screen

• Static guide lines on rear-view camera display

• Remote air conditioning system

• Clean air filter

• Front sports seats

• Manually height-adjustable driver seat

• 60:40 split-folding rear seats

• Front power windows

• Rear power windows

• Auto up & down function on all power windows

• Anti-jam protection on power windows

• UV-filter on driver & front passenger windows

• UV-filter on rear windows

• Rear window defogger

• Time adjustment on intermittent wiper

• Front room lamp (bulb type)

• Driver & front passenger personal lamps (bulb type)

• 2nd row rear passenger personal lamps (LED type)

• Boot lamp

• Lamp on driver sun visor

• Lamp on passenger sun visor

• Mirror on driver sun visor

• Mirror on passenger sun visor

• Front 12V power outlet

• Power door lock

• Child safety door lock

• Coloured TFT information displays

• Hybrid System Indicator

• Audio switches on steering wheel

• Telephone switch on steering wheel

• Voice recognition switch on steering wheel

• Lane Departure Alert switch on steering wheel

• Front pillar assist grips

• Centre pillar assist grips

• Multimedia switches on steering wheel

• Manual tilting steering wheel

• Manual telescopic steering wheel

• 12.3" screen for information display

• Pollen air filter with deodorising odour eliminator

Transport

• Centre console box

• Lid on centre console box

• Single compartment glovebox

• Glovebox lamp

• Slow-opening on lower glovebox

• Front door pockets

• Rear door pockets

• Front cup holders

• Rear passenger coat hooks (2)

• Hard tonneau cover

• Hooks for luggage holding net

Protection

• Driver & front passenger fabric floor mats

Performance

• Stop & Start System

Safety

• Supplemental Restraint System (SRS) airbags - 3 airbags

• ISOFIX seat fixing

• Rear seat belt reminder

• Front passenger airbag on/off-switch

• Front seat belt reminder

• Driver & front passenger Whiplash Injury Lessening (WIL) seats

• Rear headrests (3)

• Pre-tensioners and force limiters

• Adjustable rear headrests

• Driver & passenger side airbag

• Rear Seat Reminder System (RSRS)

• Driver knee airbag

• Toyota Safety Sense with Over-the-Air Updates

• Euro Class emission

  EURO 6 EA

• Fuel Grade - Recommended

  95 or more (octane)

• Euro Class

  EURO 6 EA

• Fuel Tank Capacity (l)

  43 l

• Sound Level Stationary (dB(A))

  67 dB(A)

• Sound Level Drive By (dB(A))

  67.0 dB(A)

• Fuel Combined WLTP (l/100 km)

  4.7 l/100 km

• CO2 Combined WLTP (g/km)

  105 g/km
